Fully Hydraulic Core Drill XZHP-LD1200A
Fully Hydraulic Core Drill XZHP-LD1200A
| Drill Rig Model | XZHP-LD1200A Core Drill Rig | |
| Diesel Engine | Diesel Engine Model | Dongfeng Cummins QS95.5-C180-33 |
| Displacement | 5.9L, 6-cylinder, National III Emission Standard | |
| Power | 133kw | |
| Maximum Rotational Speed | 2200rpm | |
| Drilling Capacity | Drill Pipe Specification | Drilling Depth |
| BQ | 1500m | |
| NQ | 1200m | |
| HQ | 950m | |
| PQ | 650m | |
| Power Head Capacity | Rotational Speed | Stepless Speed Regulation 0-1600rpm |
| Maximum Torque | 1700Nm | |
| Type | Through-shaft Type | |
| Maximum Pull-out Force | 180kN | |
| Maximum Feeding Force | 50kN | |
| Winch Capacity | Lifting Force (Single Rope) | 10kN (No-load) |
| Steel Wire Rope Diameter | 6mm | |
| Steel Wire Rope Length | 1300m | |
| Mast | Mast Adjustment Angle | 0°-90° |
| Drilling Angle | 45°-90° | |
| Feeding Stroke | 1900mm | |
| Mast Sliding Stroke | 800mm | |
| Others | Total Weight | 6.5T |
| Overall Dimensions | 4850×2100×2200mm | |
| Movement Mode | Crawler Self-propelled Type | |
| Mud Pump | Model | Daxiang BW-160 |
| Lower Clamp | Clamping Range | 56.5mm-118mm |
